ASUS – Asus Mini PC PN53 Barebone (PN53-B-S7085MD), Ryzen 7 7735HS, DDR5, 2.5″/M.2, HDMI, DP, USB-C, 2.5G LAN, Wi-Fi 6E, VESA – No RAM, Storage or O/S

SKU: PCAUPN53-B-S7085MD

AMD Ryzen Processors and AMD Radeon ™ Graphics, supports Quad-4K displays and 8K resolution, 2x PCIe® Gen4x4 M.2 NVMe™ SSD, 2.5 Gb LAN, WiFi 6E

  • Powered by the latest AMD Ryzen Processor with Radeon™ graphics
  • Quad-4K displays support and 8K UHD support
  • Support 7 USB ports, including 2 x USB 4 Type C ports, and on-board dual HDMI ports
  • Features Two-Way AI Noise Cancelation to provide crystal-clear online voice communication
  • Support DisplayPort 1.4 & Power Delivery input through rear USB Type C port
  • Onboard 2.5GbE LAN delivering faster Ethernet connectivity
  • Multi-storage design, support up to up to 2x M.2 PCIe Gen4x4 SSD and 1x HDD
  • Integrated Wi-Fi 6E and Bluetooth for easy cordless connections
  • 24/7 reliability — Extensively tested to ensure long-term dependability



Ultra-compact Mini PC provides flexible, comprehensive solutions

ASUS ExpertCenter PN53 is no lightweight when it comes to performance. It harnesses the power of the latest AMD Ryzen processor combined AMD Radeon™ 600M series graphics, and can accommodate multiple storage combinations. There's also two ultrafast PCIe®Gen 4 SSD slots and DDR5 support to ensure fast boot times and rapid app loads.

System & CPU Performance

PN53 delivers a system performance uplift of up to 10% better performance in daily multitask computing, comparing to previous generation – providing powerful computing capacity and enabling easy multitasking and smooth operation.

Graphics Performance

ExpertCenter PN53 gets a significant graphical boost with Radeon™ Graphics to deliver crisp, clear visuals that are way ahead of its class. It delivers a marked improvement, raising its score from 55% in 3DMark Fire Strike and increasing 49% 3DMark Night Raid performance benchmarks.

Ultrafast PCIe® 4.0 SSD

PCIe 4.0 doubles the data transfer rate of the prior PCIe 3.0 standard. ExpertCenter PN53 support one PCIe Gen4 x4 SSD to deliver greater data performance and lower latency.

Versatile USB 4 Type-C

Power Delivery
The Power Delivery (PD) function can either receive power from a supported display* or supply power to mobile devices.

Superfast data transfers
Experience up to 40 Gbps data transmission speeds with USB

DisplayPort™
Enjoy up to 8K @ 30 Hz video output

Faster and Better DDR5 RAM

ASUS ExpertCenter PN53 is powered by the new AMD CPU supporting the next gen memory – DDR5. With DDR5 4800MHz memory that is 1.5X faster and 8% more energy efficient than DDR4 3200MHz memory, PN53 provides excellent performance for daily computing tasks.

4K Resolution & Quad Display Support

Integrated AMD Radeon 600M series graphics enable ExpertCenter PN53 to display stunning 4K UHD videos and imagery. With HDMI, USB-C DisplayPort and a configurable port that can be specified for video signal output, PN53 lets you extend your workspace across up to four displays.

Ultra-realistic 8K Visuals

ExpertCenter PN53 supports stunning 8K UHD visuals via USB 4 or the configurable video output ports for detail four times greater than 4K, or a remarkable 16 times that of traditional FHD visuals. PN53 is capable of pumping out 8K imagery at 30 Hz via USB 4 or DisplayPort 1.4; or up to 60 Hz through HDMI 2.1* to bring images to life.

Exceptional Connection Experience – Wi-Fi 6E

The built-in WiFi 6 module allows ExpertCenter PN53 to deliver smooth high-resolution video streams, fewer dropped connections, and faster performance farther away from the router, even in dense environments. WiFi 6E is an expanded version of WiFi 6 to support high-speed 160 MHz channels.

Superfast 2.5 Gbps Networking

2.5 Gb Ethernet provides superfast networking and data transfer speeds for efficient, productive multitasking.

Easy modification, maximum possibilities

An optional multi-storage design that accommodates up to two PCIe Gen4 M.2 SSD and a 2.5-inch solid-state drives(SSD) or hard disk drives (HDD) for added storage flexibility.

Power Delivery (PD) – Input & Output

PD input lets the monitor*  provide power to ExpertCenter PN53 via a single USB-C cable, allowing for a neater workstation. ExpertCenter PN53 is able to receive power and deliver a DisplayPort signal via this connection, and also supply power to charge mobile devices.

Extreme cooling

To unleash high-end performance in such a compact machine, ASUS designers and engineers fine-tuned every aspect of the ExpertCenter PN53’s cooling system. The self-cleaning fan module includes flat heat pipes that are connected to full-sized heatsinks and fan outlets. This comprehensive cooling solution enables the CPU to operate at optimum temperatures for stronger performance that lasts.

Anti-Dust Self-Cleaning System

The Anti-Dust Self-Cleaning System not only keeps the heatsinks clean, but also effectively ejects the dust and other particles to prolong the lifespan of the system. The fan is never overworked, so less noise is generated for a quieter workstation.


Two-Way AI Noise Cancelation
Filters unwanted noise from the microphone and incoming audio for crystal-clear voice communication.




Hardware diagnostic
Scenario check-up
Provides brief descriptions to enable users to identify different situations encountered and select the ideal diagnostic checkup required.



Other Functions


WiFi SmartConnect
Optimizes the wireless connection
TaskFirst
Allocate networking bandwidth to specific tasks.
Link to MyASUS
Allows users to connect the computer to a mobile device.





Compare

£591.15

38 in stock

Compare

Description

Currently have  38 in stock!

Description

Specification

  • #Hide#Fully Built / Barebone: Barebone
  • Tower / Small Form Factor: Small Form Factor
  • Chassis: Asus Mini PC PN53
  • Processor: AMD Ryzen 7 7735HS (3.2GHz)
  • Processor Details: 8-Core
    Up to 4.75GHz boost
    35W TDP
  • Chipset: Integrated
  • Graphics: Integrated Radeon Graphics
  • #Hide#Processor: AMD Ryzen 7
  • Memory: None
  • Memory Details: 2 x DDR5 SO-DIMM Slots
    Max. 2x 32GB
  • Hard Drive: None
  • SSD Drive: None
  • Optical Drive: None
  • Supported Drives: 1 x 2.5″” SATA (supports 1TB 7200RPM 7mm HDD)
    2 x M.2 2280 – PCIe Gen4x4 (max 2TB)
  • Operating System: No O/S
  • Front I/O: 1 x USB 4 Type-C (w/ DP output)
    2 x USB 3.2 Gen1 Type-A
    1 x Audio Jack
    1 x Kensington Lock(side)
  • Back I/O: “1 x USB 4 Type-C (w/ DP output, PD input)
    3 x USB 3.2 Gen1 Type-A
    2 x HDMI
    1 x DisplayPort 1.4
    1 x 2.5G RJ45 LAN
    1 x Padlock ring
    1 x DC-in”
  • LAN: 2.5G LAN
  • Wireless: Wi-Fi 6E
  • Bluetooth: Bluetooth 5.2
  • Sound: Realtek ALC3251 HD Audio CODEC
    Two-Way AI Noise Cancelation
  • Power Unit: 150W Power Adapter
  • Keyboard and Mouse: No
  • Dimensions: 120 x 130 x 58 mm
  • Additional Features: See Overview
  • Accessories: AC Adapter
    Power Cord
    Screw Pack
    User Manual
    Warranty Card
    VESA Mount (optional)
  • Package Weight: 1.8000 kg
  • Package Type: Retail
  • Warranty: 3 Years
  • #Hide#Memory: DDR5
